Car Air Spring Hydraulic Hose Crimping Machine Tool For Mercedes Suspension Repair Kits
Product Details:
| Place of Origin: | China |
| Brand Name: | TM |
| Model Number: | all kinds of model Mercedes, BMW, Audi, Land rover, Toyota |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Price is Negotiable |
| Packaging Details: | Packed in carton firstly,and then reinforced with wooden case for outer packing |
| Delivery Time: | 1 month after received your payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 3,000pcs per month |
|
Detail Information |
|||
| Size: | L850*W900*H1300mm | Crimping Range: | 20MM-175MM |
|---|---|---|---|
| Weight: | 370Kg | Crimping Force: | 100T |
| Acurracy: | 0.05mm | Voltage: | 380V， 220V |
| Power: | 4kw | System Pressure: | 30Mpa |
| Highlight: | hose crimping machine,hydraulic hose crimp machine |
||
Product Description
Air Suspension Crimpimg Machine Hydraulic Crimping Tool For Air Suspension Air Shock Air Spring Mercedes-benz Audi BMW Land Rover
Production Description
Crimping Force: 100T
Crimping Range: 20mm-175mm
Standard Die Sets: 10 sets (the size can be done as your requests)
Voltage: 380V and 220V(according to customer requests)
Power: 4Kw
System Pressure: 30 Mpa
Accuracy: 0.05mm
Dimension: L850*W900*H1300mm
Gross Weight: 370Kg(includ 10 moulding sets)
Warranty: 12 Months
Appliion: Vehicle Air Suspensions, Air Springs, shock absorber
After Sales Service: We can give technical support for any problem any time
Package: Strong Wooden Box with Pallet
| Crimping force : 100T | ||
| Max opening : 175mm | ||
| Crimping range : 20mm-175mm | ||
| Acurracy : 0.05mm | ||
| Standard dies sets : 10 (size customized) | ||
| Voltage : 380V / 220V | ||
| Power : 4kw | ||
| System pressure : 30Mpa | ||
| Operate mode : auto , manual , pedal | ||
| Weight : 350kg-370kg | ||
| Dimension : L850*W900*H1300mm | ||
| Crimping way : Transverse withhold |
We have upgrated the crimping machine.
Here are some more advantages.
Promote Air Suspension Crimping Machine
Foot pedal of the machine controller was painted in accordance with the safety standards and different color on hydraulic presses. Was installed the connector to connect the foot pedal to the machine.
Crimping machine have been painted wear-resistant, preferably - polymeric paint RAL 5015 that reached to EU requirements.
Have been installed LED-lamps to illuminate the work area of the crimping head.
Have been installed four wheels for easy movement of the machine in the service centre.
Have been installed lifting plate for fixed and lifted the air spring and air shock.
We can offer you 10 moulding sets free .
This machine can be valid to place rings all the usual models such as W164 Front and rear Audi A6 C5, w221, w220, Land Rover BMW and etc.
The brief introduction of high pressure hose crimping machine:
Crimping machine connect rubber, plastic and steel rings through hydraulic power. It applies locking pressure through the mold of crimping machine to swage the metal joint on the matched auto air springs and high-pressure oil pipes, so as to complete the installation assembly.
It’s applicable to air spring, all kinds of machinery high and low pressure oil tube, air tube, automobile power steering tube, oil pipe, gasoline supply pipe, as well as buckling of construction fittings and hot water pipe.
It’s also widely used in vehicle, engineering machinery, hydraulic machinery, agricultural machinery and so on.
This is our new hydraulic hose crimping machine, can crimp all types of hydraulic hoses:
1. Air spring crimping machine provided with die sets range for 1/4' to 1 1/4' ID hoses.
2. Double angular surface-swaging force up to 450T, powerful yet makes crimping easy.
3. Piston,Cylinder,All dies are wire cut after hardening and grinding.
4. Powder coating body give it a Futuristic sleek & stylish looks.
Our Customers Normally Ask These Questions About the Machine:
1. What does this machine used for?
It can be used to repair or manufacture air suspensions, air aprings for cars and trucks. and aslo the industrial hydraulic hose pipes.
2. What is Voltage of this machine?
Original Voltage is 380V or 220V, but we can also make according to your requirements
3. Is it simple to learn to opearte this machine?
It is easy for operating. we will give detailed instruction and CD to show our customers how to operate
4. How to determine the dimensions of the die sets?
We process the die sets according to your dimensions or you tell us what products you want to crimp, then we can determine the size.
5. how are you going to package the machine to prevent damage during shipping?
we will pack the machine with strong wooden box with pallet to insure the safety of the machine during shipping.
We Also Supply Many Other Types of Air Suspension Shock Absorber for Mercedes, For BMW, For Audi, LandRover, For Jaguar, For Touareg, For Porsche and etc.
| Air Suspension Shock Absorber For MercedesBenz | |
| W230 | A2303200438 A2303200338 A2303208613 A2303208513 |
| W251 | A25132019312513203013 2513200425 2513203113 |
| W164 | 1643206013 1643206113 1643202031 1643200625 |
| W220(4 Matic) | A2203202238 A2203202138 2203202138 2203202238 |
| W220 | 2203202438 2203205013 |
| W221(4 Matic) | A2213200438 A2213200538 2213200438 2213200538 |
| W221 | A2213205613 A2213205513 2213205513 2213205613 |
| W211 | A2113206113 A2113206013 2113209413 2113209313 |
| Air Suspension Shock Absorber For BMW | |
| F02 | 37126791675 37126791676 |
| E66(with ADS) | 37126785535 37126785536 |
| E65 E66 | 37126785537 37126785538 |
| E53 X5 Front | 37116757501 37116757502 37116761443 37116741444 |
| E39 | 37121094613 37121094614 |
| E53 X5 Rear | 37126750355 37121095579 37126750356 37121095580 |
| Air Shock Absorber For LandRover | |
| Rangerover | RNB000740G RNB000750G L2012885 |
| Landrover Sport | LR019993 LR023234 |
| Discovery 3 | RNB501580 RTD501090 |
| RangeRover L322 | LR012885 LR032567 LR012859 LR032560 |
| Airmatic Shock Absorber For Audi VW | |
| A6 4F C6 AVANT) | 4F0616039AA 4F0616040AA |
| Q7 For Porsche(Front) | 7L6616039D 7L6 616 040D |
| Q7 For Porsche(Rear) | 7L5616019D 7L5616020D |
| Q7(Front) | 7P6616039N 7P6616040N |
| A8 D3 Front | 4E0616039AF 4E0616040AF |
| A8 D4 | 4H0616039AD |
| VW For Phaeton(Front) | 3D0616039D 3D0616040D 3D0616001J 3D0616002J |
| A6 C5 Allroad | 4Z7413031A 4Z7616051B 4Z7616051D 4Z7616052A 4Z7616051A |
| A8 D3 rear | 4E0616001E 4E0616002E |
We Also Supply Many Other Types of Air Suspension Compressors
| Air Suspension Compressor For MercedesBenz | |
| W221 | A2213200704 |
| W220 | A2203200104 |
| W164 | A1643201204 |
| W166 | A1663200104 |
| W251 | A2513202704 |
| Air Suspension Compressor For BMW | |
| E53 | 37226787617 |
| E39 E65 E66 | 37226787616 |
| X5 E70 | 37226775479 |
| F01 F02 | 37206789450 |
| Air Suspension Compressor For LandRover | |
| RangeRover L322 | LR0060201 |
| RangeRover 2006-2012 | LR02511 |
| Rover 2006-2012 | LR041777 |
| LandRover Discovery | LR045251 |
| Discovery 3 4 RangeRover Sport | LR023964 |
| Air Suspension Compressor For Audi | |
| A6 4B C5 Allroad | 8W1Z5319A |
| A6 4F C6 AVANT) | 4F0616005E |
| Q7 | 4L0698007A |
| A8 | 4E0616005D |
| A6 C5 | 4Z7616007A |
| A6 | 4F0616005D |
We also have air suspension crimping machine for air shock absorber air spring for Mercedes for BMW for Landrover for Audi and other models.
Contact Us:
If you have any questions, please feel free to contact with us. We would be very glad to help you. We will get back to you within 24 hours or get back to you immediately.
Standard dies sets
